Toonflow

AI Short Drama Factory
With a tap, novels instantly become episodes!
AI scripts × AI visuals × Turbo generation 🔥

🚀 One-stop short drama production: From text to characters, from storyboard to video, 0 barrier full-process AI, 10x+ creation efficiency!

🌟 Main Features

Toonflow is an AI short drama comic tool that leverages AI technology to automatically convert novels into scripts, and uses AI-generated images and videos for efficient short drama creation. With Toonflow, you can easily complete the entire process from text to images, making short drama production more intelligent and convenient.

✅ Character Generation
Automatically analyzes the original novel text, intelligently identifies and generates character settings, including appearance, personality, identity, etc., providing a reliable foundation for subsequent script and visual creation.
✅ Script Generation
Based on selected events and chapters, the system automatically generates structured scripts, covering dialogue, scene descriptions, and plot direction, enabling efficient transformation from literary texts to film/TV scripts.
✅ Storyboard Production
Based on the script content, intelligently generates storyboard prompts and visual design, detailing foreground/midground/background, character dynamics, prop settings, and scene layout; automatically turns scripts into storyboards, providing a complete route blueprint for video production.
✅ Video Composition
Integrates AI image and video technologies to generate video clips using AI. Includes online editing and supports personalized output adjustments, making film & TV production collaborative and efficient.

📦 Application Scenarios

Short video content creation
Novel-to-film/TV experiments
AI literature adaptation tools
Script development and rapid prototyping
Video material generation

🔰 User Guide

📺 Video Tutorial

https://www.bilibili.com/video/BV1na6wB6Ea2

Toonflow 8-Minute Quick Start AI Video 👉 Click to watch

📱 Scan with WeChat on your phone to watch

🚀 Installation

Prerequisites

Before installing and using this software, please prepare the following:

✅ Large language model AI service API address
✅ Sora or Doubao video service API address
✅ Nano Banana Pro image generation model service API

Local Installation

1. Download & Install

Operating System	GitHub Download	Quark Cloud Download	Notes
Windows	Release	Quark Cloud	Official installer
Linux	Release	Quark Cloud	Official installer
macOS	Release	Quark Cloud	Official installer

Caution

On MacOS, please go to Settings - Privacy & Security to configure security settings, otherwise, you may not be able to open the app due to certificate issues.

See Zhihu documentation: https://www.zhihu.com/question/433389276

Due to Gitee OS environment and Release file upload size limits, Gitee Release download is currently not available.

2. Start Service

After installation, launch the program to start using this service.

⚠️ First-time Login
Username: admin
Password: admin123

Docker Deployment

Prerequisites

Docker installed (version 20.10+)

Method 1: Online Deployment

To be developed; please use local build for now.

Method 2: Local Build

Build directly from local source code, suitable for developers or users who have cloned the repo; requires Git installed locally:

# Clone the project (skip if already cloned)
git clone https://github.com/HBAI-Ltd/Toonflow-app.git
cd Toonflow-app

# Build and start locally with docker-compose
yarn docker:local

# Or build manually
docker build -t toonflow .
docker run -d -p <local_port>:10588 -v <local_data_path>:/app/data toonflow

# After this, the site can be accessed at /web/index.html on the mapped port
# e.g. http://localhost:10588/web/index.html

Service Port Description

Port	Purpose	Deployment Mapping
`10588`	App Interface	`10588:10588`

Environment variable descriptions:

Variable	Description
`NODE_ENV`	Environment; `prod` for production
`PORT`	Service listening port (default 10588)
`OSSURL`	File storage access address for static files

Cloud Deployment

1. Server Requirements

OS: Ubuntu 20.04+ / CentOS 7+
Node.js: 24.x (recommended, minimum 23.11.1+)
RAM: 2GB+

2. Server Deployment

1. Install Environment

# Install Node.js
curl -o- https://raw.githubusercontent.com/nvm-sh/nvm/v0.39.7/install.sh | bash
source ~/.bashrc
nvm install 24
# Install Yarn and PM2
npm install -g yarn pm2

2. Deploy Project

Clone from GitHub:

cd /opt
git clone https://github.com/HBAI-Ltd/Toonflow-app.git
cd Toonflow-app
yarn install
yarn build

Clone from Gitee (Mainland China recommended):

cd /opt
git clone https://gitee.com/HBAI-Ltd/Toonflow-app.git
cd Toonflow-app
yarn install
yarn build

3. Configure PM2

Create a pm2.json file:

{
  "name": "toonflow-app",
  "script": "data/serve/app.js",
  "instances": "max",
  "exec_mode": "cluster",
  "env": {
    "NODE_ENV": "prod",
    "PORT": 10588,
    "OSSURL": "http://127.0.0.1:10588/"
  }
}

Environment variable descriptions:

Variable	Description
`NODE_ENV`	Environment; `prod` for production
`PORT`	Service listening port
`OSSURL`	File storage access address for static files

4. Start Service

pm2 start pm2.json
pm2 startup
pm2 save

5. Common Commands

pm2 list              # View process list
pm2 logs toonflow-app # View logs
pm2 restart all       # Restart service
pm2 monit             # Monitoring panel

⚠️ First-time Login
Username: admin
Password: admin123

6. Deploying the Frontend Website

For standalone frontend deployment or customization, refer to the frontend repository:

GitHub: Toonflow-web
Gitee: Toonflow-web

💡 Note: This repo already contains a compiled frontend by default. Regular users do NOT need to separately deploy the frontend. The frontend repo is for developers requiring secondary development.

🔧 Developer Guide

Caution

🚧 PR Submission Guidelines 🚧

⛔ master branch does NOT accept PRs | ✅ Please submit PRs to the develop branch

Developers are invited to co-develop Toonflow. To join, contact owner ACT in the group chat.

🛠️ Tech Stack

Category	Technology
Runtime	Node.js 23.11.1+
Language	TypeScript 5.x
Backend	Express 5
Database	SQLite (better-sqlite3 / knex)
AI Integration	Vercel AI SDK (OpenAI / Anthropic / Google / DeepSeek / Zhipu / MiniMax / Qwen / xAI)
Local Inference	@huggingface/transformers (ONNX)
Real-Time	Socket.IO
Desktop	Electron 40
Image Proc.	Sharp
Container	Docker

Development Environment Preparation

Node.js: version 23.11.1 or above required
Yarn: recommended as the package manager

Quick Start

Clone the project

Clone from GitHub:

git clone https://github.com/HBAI-Ltd/Toonflow-app.git
cd Toonflow-app

Clone from Gitee (Mainland China recommended):

git clone https://gitee.com/HBAI-Ltd/Toonflow-app.git
cd Toonflow-app

Install dependencies

In the project root directory, install dependencies:
```
yarn install
```
Start development environment

This project includes both backend API service and frontend interface. Start as needed:
- Option 1: Start backend service only
```
yarn dev
```
  ⚠️ This command starts only the backend API (port 10588), without the web interface. Accessing http://localhost:10588 allows API calls only; the full web UI is unavailable. To use the frontend, start the frontend project separately or use GUI mode below.
- Option 2: Start Electron desktop client
```
yarn dev:gui
```
  This command starts both backend and Electron window, with built-in web UI. Out-of-the-box, no extra config needed. Recommended for a full experience.
- Option 3: Production mode
```
yarn start
```
  Runs compiled service in production mode (requires yarn build first).
Build the project
- Compile TypeScript files:
```
yarn build
```
- Build executable for Windows:
```
yarn dist:win
```
- Build executable for Mac:
```
yarn dist:mac
```
- Build executable for Linux:
```
yarn dist:linux
```
Code quality check
- Perform lint check:
```
yarn lint
```
AI Debug panel (Optional)

Start the Vercel AI SDK visual debugging tool for easier AI integration debugging:
```
yarn debug:ai
```

Frontend Development

To modify the frontend UI, develop in the frontend repository:

GitHub: Toonflow-web
Gitee: Toonflow-web

After frontend build, copy the dist contents to this project's data/web to integrate.

Project Structure

📂 build/                    # Compiled output
📂 data/                     # Runtime data
│  ├─ 📂 models/            # Local inference models (ONNX)
│  ├─ 📂 oss/               # Object storage (assets/characters/scenes)
│  ├─ 📂 serve/             # Production entry
│  ├─ 📂 skills/            # Agent skill prompts
│  └─ 📂 web/               # Built-in frontend assets
📂 ./                     # Documentation assets
📂 env/                      # Environment configs
📂 scripts/                  # Build and helper scripts
📂 src/
├─ 📂 agents/               # AI Agent modules
│  ├─ 📂 productionAgent/   # Production Agent
│  └─ 📂 scriptAgent/       # Script Agent
├─ 📂 lib/                  # Common libraries (db, responses)
├─ 📂 middleware/           # Middleware
├─ 📂 routes/               # API routes
│  ├─ 📂 agents/            # Agent memory management
│  ├─ 📂 artStyle/          # Art style management
│  ├─ 📂 assets/            # Asset management
│  ├─ 📂 assetsGenerate/    # Asset generation
│  ├─ 📂 cornerScape/       # Storyboard management
│  ├─ 📂 general/           # General APIs
│  ├─ 📂 login/             # Auth
│  ├─ 📂 migrate/           # Data migration
│  ├─ 📂 modelSelect/       # Model selection
│  ├─ 📂 novel/             # Novel management
│  ├─ 📂 other/             # Other features
│  ├─ 📂 production/        # Production management
│  ├─ 📂 project/           # Project management
│  ├─ 📂 script/            # Script generation
│  ├─ 📂 scriptAgent/       # Script Agent APIs
│  ├─ 📂 setting/           # System settings
│  ├─ 📂 task/              # Task management
│  └─ 📂 test/              # Test APIs
├─ 📂 socket/               # WebSocket comms
├─ 📂 types/                # TypeScript types
├─ 📂 utils/                # Utility functions
├─ 📄 app.ts                # App entry point
├─ 📄 core.ts               # Core initialization
├─ 📄 env.ts                # Env vars
├─ 📄 err.ts                # Error handling
├─ 📄 logger.ts             # Logging module
├─ 📄 router.ts             # Route registration
└─ 📄 utils.ts              # General tools
📄 Dockerfile                # Docker build config
📄 electron-builder.yml      # Electron packaging config
📄 skillList.json            # Skills list
📄 LICENSE                   # (Apache-2.0) License
📄 NOTICES.txt               # Third-party dependencies
📄 package.json              # Project config
📄 tsconfig.json             # TypeScript config

Repository	Description	GitHub	Gitee
Toonflow-app	Full client (this repo, for users)	GitHub	Gitee
Toonflow-web	Frontend source (for FE devs)	GitHub	Gitee

💡 Tip: If you just want to use Toonflow, download the client from this repo directly. The frontend repo is for developers needing secondary dev or UI customization.

👨‍👩‍👧‍👦 WeChat Groups

~~Group 1~~

~~Group 2~~

...

~~Group 10~~

~~Group 11~~

~~Group 12~~

~~Group 13~~

...

~~Group 24~~

Group Assistant:

💌 Contact Us

📧 Email: [ltlctools@outlook.com](mailto:ltlctools@outlook.com?subject=Toonflow inquiry)

📜 License

Toonflow is open source under Apache-2.0 with a supplementary commercial agreement.

License details: https://www.apache.org/licenses/LICENSE-2.0

Supplementary Agreement

If you distribute this software as a product to 2 or more independent third parties, you must obtain written commercial authorization from HBAI-Ltd.
≤ 5 legal entities operating jointly for internal use without providing services externally are considered internal use and require no authorization.
You may not remove or modify any trademarks, logos, or copyright notices in Toonflow.

Always Free — No Authorization Required

✅ Using Toonflow to produce content and earn platform revenue shares
✅ Secondary development for internal team use
✅ ≤ 5 legal entities operating jointly, internally only
✅ Personal learning, research, and non-commercial purposes

Licensing Pricing

Stage	Annual Revenue	Annual Fee
🌱 Nurture	< $10k	Free
🚀 Startup	$10k–$50k	¥5,000/year
📈 Growth	$50k–$150k	¥20,000/year
🏢 Scale	$150k–$500k	¥80,000/year
🌐 Enterprise	> $500k	Negotiable

Non-Retroactivity Clause: Users who used Toonflow under AGPL-3.0 prior to the v1.0.8 release are not affected by this change. Their existing usage continues under AGPL-3.0.

See the full LICENSE file for details.

⭐️ Star History

🙏 Thanks

Thank you to the following open-source projects for supporting Toonflow:

Express - Fast, open, minimalist Node.js Web framework
AI SDK - TypeScript-first AI toolkit
Better-SQLite3 - High-performance SQLite3 bindings
Sharp - High-performance Node.js image toolkit
Axios - Promise-based HTTP client
Zod - TypeScript-first schema validation library
Socket.IO - Real-time bidirectional event framework
Electron - Cross-platform desktop app framework
Hugging Face Transformers - Local ML inference library

Thanks to the following organizations/individuals for their support:

SophNet Cloud provides computing power sponsorship [Official Website]

For a complete list of third-party dependencies, see NOTICES.txt

20 KiB Raw Blame History Unescape Escape

Toonflow

🌟 Main Features

📦 Application Scenarios

🔰 User Guide

📺 Video Tutorial

🚀 Installation

Prerequisites

Local Installation

1. Download & Install

2. Start Service

Docker Deployment

Prerequisites

Method 1: Online Deployment

Method 2: Local Build

Service Port Description

Cloud Deployment

1. Server Requirements

2. Server Deployment

1. Install Environment

2. Deploy Project

3. Configure PM2

4. Start Service

5. Common Commands

6. Deploying the Frontend Website

🔧 Developer Guide

🛠️ Tech Stack

Development Environment Preparation

Quick Start

Frontend Development

Project Structure

🔗 Related Repositories

👨‍👩‍👧‍👦 WeChat Groups

💌 Contact Us

📜 License

Supplementary Agreement

Always Free — No Authorization Required

Licensing Pricing

⭐️ Star History

🙏 Thanks

20 KiB

Raw Blame History
